The most advanced DT Swiss aero disc brake wheelset for new top speeds while handling the bike safely anytime.
The latest generation of ARC 1100 DICUT wheels – available in disc brake version in three different rim heights 80 mm, 62 mm and 50 mm – was developed in cooperation with SWISS SIDE, leading expert in aerodynamic optimization. Consequently, the new AERO+ rim profile minimizes both aero drag and steering moment to improve its aerodynamic and controlling in even strong cross wind. Thus, it makes it easier for the rider to keep the aero wheel under control while taking advantage of the forward-pushing sailing effect. The wheel setup is completed by the new DT Swiss aero spokes in combination with the sleek 180 DICUT hub including ultra-light running SINC ceramic bearings.
| REAR WHEEL | FRONT WHEEL | |
| GENERAL | ||
| NET WEIGHT | 942 g | 820 g |
| RECOMMENDED SYSTEM WEIGHT MAX. | 110 kg | 110 kg |
| ASTM CLASSIFICATION | 1 | 1 |
| RIM | ||
| MATERIAL | Carbon | Carbon |
| RIM JOINT | - | - |
| TIRE INTERFACE | Hooked / Crotchet tubeless TC | Hooked / Crotchet tubeless TC |
| VALVE HOLE | Presta | Presta |
| RIM DIAMETER | 29" / 700C | 29" / 700C |
| RIM HEIGHT | 80 mm | 80 mm |
| DECAL TYPE | Waterslide | Waterslide |
| INNER WIDTH | 20 mm | 20 mm |
| OUTER WIDTH | 32 mm | 32 mm |
| HUB | ||
| HUB TYPE | 180 | 180 |
| AXLE SYSTEM | 12 mm Thru Axle | 12 mm Thru Axle |
| BUILT-IN DIMENSION | 142 mm | 100 mm |
| BRAKE INTERFACE | Disc Center Lock | Disc Center Lock |
| FREEHUB BODY | Shim. RD. 11SP Light S ASLS11 | - |
| FREEHUB SYSTEM | Ratchet EXP 36 | - |
| SPOKES & NIPPLES | ||
| SPOKES LEFT | DT aerolite® II t-head | DT aerolite® II t-head |
| SPOKES RIGHT | DT aero comp® II t-head | DT aerolite® II t-head |
| SPOKE PATTERN | Two-cross (1:1) | Two-cross (1:1) |
| NIPPLES | DT Pro Lock hidden aluminum | DT Pro Lock hidden aluminum |
| INCLUSIVE | ||
| Tubeless tape 23 mm | Tubeless tape 23 mm | |
| TL valve alu black 66-80 mm | TL valve alu black 66-80 mm | |
| SRAM XDR Road freehub body kit | 5 mm endcap Kit | |
| 5 mm endcap Kit | valve guard | |
| valve guard | wheel bag | |
| wheel bag |
