Top-end SCULTURA featuring not just the best components that can be found in the world of road cycling but also our latest CF5 carbon frame. The test-winning frame offers low weight, but also improved aerodynamics and class-leading comfort.
Frame: SCULTURA CF5 V; MAT carbon; 700x30C max. WHS; 100x12/ 142x12 AST; Pressfit 86,5
Size: S-M-L-XL
Fork: SCULTURA CF5 disc; MAT carbon; 700x30C max. WHS
Gears: 2 x 12
Chainwheel: Shimano Dura Ace; 52-36 ATC; Power Meter
Crank/Size: 165 mm-XXS/XS, 170 mm-S, 172.5 mm-M, 175 mm-L/XL
Bottom Bracket: SM-BB92-41B, Pressfit 86.5
Cassette: Shimano CS-R9200; 11-30 ATC; 12 GER
Chain: Shimano CN-M9100-12
Derailleur - Front: Shimano Dura Ace Di2
Derailleur - Rear: Shimano Dura Ace Di2
Shifters: Shimano Dura Ace disc Di2
Brakes: Shimano Dura Ace; Hydraulic disc
Rotor - Front: Shimano CL900; 160mm
Rotors - Rear: Shimano CL900; 140mm
Handlebar: TEAM SL 1P INTEGRATED; MAT carbon; 400mm (XXS-XS-S), 420mm (M), 440 (L-XL)
Stem: TEAM ONE-PIECE INTEGRATED; MAT carbon
Stem/Size: 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL
Head Set: MERIDA custom
Seat Post: MERIDA Team SL; 27.2 DSP; 15 SSB; Carbon; S-Flex
Saddle: SCRATCH M5
Hub-Front: attached
Hub-Rear: attached
Axle-Front: MERIDA EXPERT SL
Axle-Rear: MERIDA EXPERT SL; including removable lever; 6/4mm allen key
Spokes: attached
Rims: ZIPP 353 NSW TL Disc; 100x12 WHF; 142x12 WHR; 25 IWR; 45 HRI; Centerlock; MAT carbon; Tubeless ready (tubeless tape and valves included)
Tyres: Continental Grand Prix 5000S TR; 700x28C; fold; tubeless ready
Bottle Cage: MERIDA B-147-B CARBON BOTTLE CAGE X 2
E-Shift Parts: Battery BT-DN300
E-Shift Parts: Charging Cable, EW-EC300
Other: MERIDA Multitool with saddlebox
Other: Garmin Carrier + Garmin insert*2 + GoPro/Light Mount
Max Rider Weight: 120kg
