Whether you want to liven up your everyday urban riding or head off on a bigger adventure, this sleek mix of Shimano e-power, practicality and fun has you covered for all occasions.
Frame: eBIG.TOUR LITE IV; MAT aluminium; 29x2.35" without fender max./ 29"x2.25" with fender max. WHS; 148x12 AST; intube
Sizes: S-M-L-XL
Fork: Suntour XCR34 LOR DS; Air Boost; 100mm; Tapered; 51mm fork offset; 29x2.4" max WHS
Drive Unit: Shimano EP6; 85Nm
Battery: Simplo Internal Battery Gen 2; 750Wh
Battery Charger: Trendpower EU Charger; 4A
Display: Shimano SC-EN600
Rear Derailleur: Sram NX Eagle
Shifters: Sram NX EAGLE 12
Brake - Front: Sram DB8; 4 piston
Brake - Rear: Sram DB8; 4 piston
Rotor - Front: Sram CenterLine; 180mm
Rotor - Rear: Sram CenterLine; 180mm
Chainwheel: SAMOX EMA04; 34 ATC
Crank/Size: Shimano FC-EM600; 165mm
Chain: Sram SX Eagle
Cassette: Sram PG-1210 Eagle; 10-50 ATC; 12 GER
Pedals: VP VPE-537
Handlebar: MERIDA EXPERT CC; MAT aluminium; 720 WHB; 10 RHB
Handlebar Stem: MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable
Stem Length: 90 mm all sizes
Seat Post: MERIDA EXPERT CC; MAT aluminium; 34.9 DSP; 0 SSB
Saddle: MERIDA EXPERT TK; V-mount
Hub - Front: Novatec SL-ELITE D041SB-B15; 110x15 WHF; 32 SPH; 6 bolt
Hub - Rear: Novatec SL-TEAM D462SB-S3S-B12-11S; 148x12 WHR; 36 SPH; 6 bolt
Axle - Rear: MERIDA EXPERT TR; including removeable lever, 6/4mm allen key
Rims: MERIDA COMP CC II; 25 IWR; MAT aluminium
Tyres: KENDA Booster; 29x2.2"; wire
Fenders: Sunnywheel SW-FA311-65A/ SW-FA311-65E1
Carrier: MERIDA MA008-1 w/spring clamp + Spanninga GLOW XE
Kickstand: CL-KA98, 29"
Light - Front: LEZYNE E-BIKE POWER STVZO E115
Light - Rear: Spanninga Commuter GLOW XE
Max Rider Weight: 140kg
