Frame: SPEEDER-D, alloy
Sizes: XS-S-SM-ML-L-XL
Fork: MERIDA SPEEDER STEEL DISC
Gears: 3 x 8
Crankset: Shimano TY301 48-38-28T
Crank Length: 170 mm all sizes
Bottom Bracket: FSA TH-7420ST, Cartridge Bearing
Cassette: Sunrace CSM668; 11-32T; 8S, silver
Chain: Sunrace M84
Front Derailleur: Shimano FD-TY710
Rear Derailleur: Shimano RD-M360
Shifters: Shimano ST-EF505
Brake Levers: Shimano EF505
Brake-Front: Shimano ST-EF505; BR-MT200 brake caliper
Brake-Rear: Shimano ST-EF505; BR-MT200 brake caliper
Rotors: Shimano RT10 160 cen
Handlebar: MERIDA CC 31.8 diameter, 600 wide, flat
Handlebar Stem: MERIDA SPEED 31.8 Diameter
Stem Length: 100 mm all sizes
Head Set: A-Head OS
Seat Post: MERIDA speed 27.2 350mm
Saddle: Merida Sport
Hub-Front: Shimano HB-TX505 cen 32H
Hub-Rear: Shimano HB-TX505 cen 32H
Axle-Front: Quick Release
Axle-Rear: Quick Release
Spokes: Black steel
Rims: MERIDA CC; 17 IWR; MAT aluminium
Tyres: MERIDA K1029; 700x30C; wire
Pedals: PP pedal ( VPE-891 )
Max Rider Weight: 120kg
